실리카졸(콜로이달실리카)

Colloidal Silica (Silica Sol)

실리카졸 YGS

Colloidal Silica YGS

HOME > 실리카졸 YGS

제품개요Description

실리카졸 또는 콜로이달실리카란 물이나 유기용제와 같은 액체에 고형의 나노사이즈 실리카 입자가 침전되거나 응집되지 않고 안정된 상태로 분산되어 있는 것을 말한다. 물에 분산된 실리카졸을 아쿠아졸 또는 하이드로졸이라고 하고, 유기용제에 분산된 실리카졸을 유기졸 또는 오르가노졸이라고 한다.

Silica sol or colloidal silica is a stable dispersion of solid silica nano-sized particles in a liquid, such as water or an organic solvent, without precipitation or agglomeration. Silica sol dispersed in water is called an aquasol or hydrosol, while silica sol dispersed in an organic solvent is called an organosol.



(주)영일화성이 제조하는 실리카졸 YGS는 수분산 실리카졸이다. 상용화되는 대부분의 수분산 실리카졸은 물유리를 출발물질로 이온교환수지법으로 제조되는 반면, 실리카졸 YGS는 고순도 규소를 수중에서 직접 산화시켜서 나노사이즈 실리카입자를 합성하는 방법으로 제조된다.

Silica Sol YGS, manufactured by YOUNG IL CHEMICAL CO., LTD., is a water-dispersed product. While most commercially available water-dispersed silica sols are manufactured using water glass as a starting material via the ion-exchange resin method, Silica Sol YGS is manufactured by directly oxidizing high-purity silicon in water to synthesize nano-sized silica particles.



실리카졸 YGS는 제법 상 특징으로 실리카 입자의 구형도가 우수하고 낮은 응집도를 갖으며 안정성이 우수하다. 실리카졸은 비정질 합성실리카의 열적 특성, 나노사이즈 실리카의 입자 특성 및 표면 특성, 겔화 특성 등을 이용하여 다양한 분야에서 응용되고 있다.

Silica Sol YGS is characterized by excellent silica particle sphericity, low agglomeration, and excellent stability. Silica Sol is applied in various fields by taking advantage of the thermal properties of amorphous synthetic silica, the particle and surface properties of nano-sized silica, and its gelation properties.

제품특징Product Features

  • ㆍ실리카 입자의 우수한 구형도와 낮은 응집도
  • ㆍ우수한 안전성
  • ㆍ안정적인 알칼리 함량
  • ㆍ용이한 실리카 입자크기 조절
  • ㆍ친환경 제조방법
  • ㆍExcellent sphericity and low agglomeration of silica particles
  • ㆍExcellent safety
  • ㆍStable alkaline content
  • ㆍEasy silica particle size control
  • ㆍEco-friendly manufacturing method

주요용도Applications

  • ㆍ정밀주조, 내화물, 세라믹 분야의 고온용 바인더
  • ㆍ졸-겔 응용, 유무기하이브리드 응용의 재료
  • ㆍ내마모성, 내슬립성, 내정전기성 등 기능성 재료
  • ㆍ연마입자
  • ㆍ비료
  • ㆍ촉매
  • ㆍHigh-temperature binders for precision casting, refractories, and ceramics
  • ㆍRaw materials for sol-gel and organic-inorganic hybrid applications
  • ㆍFunctional materials with wear resistance, slip resistance, and antistatic properties
  • ㆍAbrasive particles
  • ㆍFertilizers
  • ㆍCatalysts

알칼리 수분산 실리카졸의 제품규격Product Specifications of Alkali Aqueous Silica Sol

Product pH Specific gravity
(20±1℃)
Ma2O (wt%) SiO2 (wt%) Viscosity (cps, 20±1℃) Average Particle Size(㎚)
YGS-30 9.5-10.5 1.190-1.210 Max. 0.50 29-31 Max. 20 10-20
YGS-30S 9.5-10.5 1.190-1.210 Max. 0.50 29-31 Max. 20 10-15
YGS-30L 9.0-10.0 1.190-1.210 Max. 0.35 29-31 Max. 20 10-15
YGS-40 9.5-10.5 1.270-1.290 Max. 0.60 39-41 Max. 50 10-20
YGS-40S 9.5-10.5 1.270-1.290 Max. 0.60 39-41 Max. 50 8-12
YGS-4040 9.5-10.5 1.270-1.290 Max. 0.50 39-41 Max. 30 40-50
YGS-4080 9.5-10.5 1.270-1.290 Max. 0.50 39-41 Max. 30 80-90
YGS-2101 8.0-9.0 1.230-1.250 Max. 0.30 34-36 Max. 10 15-25

개질 실리카졸의 제품규격Product Specifications of Acid Modified Silica Sol

Product pH Specific gravity(20±1℃) Nonvolatile Content
(wt%, 250±2℃, 1hr)
Viscosity (cps, 20±1℃) Average Particle Size(㎚)
YGS-2101A 2-3 1.100-1.140 20-22 Max. 10 10-30
YGS-3101A 2-3 1.100-1.140 20-22 Max. 10 50-70
